PCD reamer

PCD reamer Design of finish machining clearance hole, cutting tool structure and drainage holes all have the
effect of reverse chip removal , makes a large number of aluminum scrap smoothly drain outside hole
in the processing, so that it can avoid congestion in cross hole of aluminum scrap , omit tedious
cleaning of aluminum, improve the high production efficiency and increase the process safety! More

PCD compound reamer

PCD compound reamer Rough machining tappet hole, and terminal guidance on the set meter,effectively restrain the vibration phenomenon during the high efficiency machining process, and it can avoid the
aluminum scraps entangle on the insert, so that it can effect on chip breaker. When cutting tool leave the factory, the dynamic equilibrium preset to level G2.5, it effectively reduce
the spindle wear and tear under the load conditions. Reliable product quality greatly increased the production efficiency. More

PCD compound reamer

PCD compound reamer Rough finish machining valve seat and catheter hole. Using quick change of the handle which has Yamada patent, not only can assure the accuracy of catheter hole,
but also can replacement very quick after the tool wear. Seat blade use BT13CBN material which developed by Yamada designed for processing the seat (powder metallurgy Material) ,
match with automatic production lines, product quality is stable, cutting tools is with a long service life. The most rapid tool grinding service maximum reduce the client unit cost! More

PCD molding reamer

PCD molding reamer Finish processing the valve seat bottom hole and catheter bottom hole,
The front end uses cemented carbide thermal design, enhance the strength
of the small diameter cutter body, fully fit to the high speed machining,
and ensure the tube bottom hole and seat bottom hole in the same axis,
high precision cutting tool size effectively assures the strict workpiece
size requirements. To process high production quality with high production
efficiency More

PCD molding reamer

PCD molding reamer Finishing oil Spray Nozzle hole,flang style shank design make up the jump of the machine shaft,that assure the good precision.The special dealing of the outlet water hole and cutting edge make the good chip removal.High safe craft improve the high production efficient. More

PCD molding reamer

PCD molding reamer Rough machining pipe orifice and transition surface, transition surface
processing uses crossing tooth design, in order to deal with the vibration
because of large margin, large contact area during the cutting, PCD insert body
can be repeated after the insert edge wear, It reduces the production cost maximam.
High cutting speed effectively improves cutting tool's service life and production
efficiency. More
